Conference phone

Conference phone

Enjoy better-quality conference calls on this dedicated IP conference phone, or use your own deskphone, PC or smartphone

overview

Enjoy better-quality conference calls on this dedicated IP conference phone, or use your own deskphone, PC or smartphone with our conferencing modules. Our range of conferencing solutions transform your conferencing experience with high-quality audio, easy connectivity to your existing platforms, and powerful conferencing features. Whether you’re accustomed to the benefits of IP voice services or looking to adapt and enhance your existing devices, our conferencing products will meet your needs. Conference phone for Large meeting room One click is all it takes to start or join a meeting with ALE Unite mobile app and the Alcatel-Lucent 8135s IP Conference Phone. This SIP device includes all IP voice services and innovative new features such as OmniSound audio with full duplex, automatic echo cancellation and noise suppression. Portable conferencing module for mobility and huddle rooms The EGO personal speakerphone is compact and portable and fits easily into a work bag. It provides OmniSound® audio technology for very high-quality HD audio conversations. Connect it to a laptop through a USB or connect to a smartphone and benefit from high-quality audio meetings wherever you are (up to 12 hours of call time)

SPECIFICATIONS

Conference phone
  • Network and provisioning
    • Ethernet 10/100BaseT (IEEE 802.3ab) • IEEE 802.3af Power over Ethernet (POE), ANSI/TIA-1057 (LLDP-MED) • DHCP and static IP • 802.1x Authentication with EAP-TLS • QoS support: IEEE 802.1p/Q (VLAN), DiffServ • Configuration methods: Browser (HTTP/HTTPS) • Support for auto-provisioning with certificate management • Time servers: NTP and SNTP (RFC4330) • Additional features: Remote syslog, PCAP-log, unique hostname
  • Languages
    • Multi-language support (menu): Danish, Dutch, English, Finnish, French, German, Italian, Norwegian, Polish, Russian, Spanish, Swedish and Turkish
  • Regulatory Standards Safety
    • EN 60950-1:2006 • IEC/UL/CSA 60950-1
  • EMC
    • EN 301 489-17 • EN 301 489 • EN 301 489-1 • FCC Part 15 subpart B class B • ICES-003 class B • EN 55032 • EN 55024 + A1 • EN 61000-3-2 • EN 61000-3-3
  • Physical characteristics
    • Width: 240 mm (9.45 in.) • Height: 77 mm (3.03 in.) • Weight: 1 kg (2.21 lbs.) • Color: Licorice black • Anti-theft protection: Kensington security slot
  • Display
    • Screen resolution: 128 x 64 pixels (5 in. x 2.5 in.) • Backlit black/white LCD display
  • Navigation and user interface
    • Keys: ¬ Alphanumeric 0–9, *, # ¬ On, off ¬ Call, call hold, end call ¬ Mute, volume +/- ¬ Contacts ¬ Conference guide • Five keys for menu navigation
  • Telephony specifications
    • Protocols: SIP, LDAP (RFC1777) • During a call: ¬ Put call on hold ¬ Call waiting ¬ Call park and pick-up ¬ Transfer incoming call ¬ Request ¬ Music on hold ¬ Dial plan • Dialing methods: ¬ Phone number ¬ SIP URI ¬ ALE Unite mobile app • Multi-party calls: ¬ Local five-way audio bridge ¬ Two configurable SIP accounts • Phone book: ¬ LDAP ¬ Four password-protected user profiles ¬ Local directory: Up to 1000 entries per user profile ¬ Export/import of contacts ¬ Call list ¬ Conference guide: 20 groups per user profile, four participants/ group • Call recording: Support for SD and SDHC memory cards
  • Audio specifications
    • Technology: ¬ OmniSound with support for HD audio ¬ Full duplex ¬ Automatic echo cancellation ¬ Noise suppression • Microphone: ¬ Omnidirectional 360˚ reception area ¬ Up to 12 people (30 m2) ¬ Optional two expansion microphones (70m2) • Speakers: ¬ Frequency range: 200-20,000 Hz ¬ Volume: max. 90 dB ¬ Sound pressure level (SPL): 0.5 m • Equalizer: Soft, neutral, bright • Codecs: G722, G711 A-law, G711 μ-law, G729ab
  • Connectivity
    • Bluetooth ¬ Low Energy Profiles ¬ GAP and GATT ¬ Only for control features, not for audio transfer • NFC for swift connection to the ALE Unite mobile app ¬ NFC Forum Type 4 ¬ ISO/IEC 14443 Type A support • USB: 2.0 Mini B port • Expansion microphones: 2x modular 4/4
  • Mobile App
    • ALE Unite ¬ Meeting notification before meeting starts ¬ Discovery of nearest 8135s IP Conference Phone: Bluetooth, NFC ¬ One touch conferencing ¬ Meeting management: Add participants, dial with keypad, mute, hold, split, hang-up ¬ Android: Google Play ¬ iOS: Apple Store
  • Telephony protocols
    • SIP v2 • DNS SRV (RFC3263) • NAT traversal: STUN, ICE and TURN • Connection protocol: SIP 2.0 (RFC 3261 and companion RFCs) • Signaling protocol: UDP, TCP, TLS and SIPS • Media protocol: RTP, SRTP • DTMF tone generation: RFC 4733/2833, SIP INFO, In-band • Alcatel-Lucent OmniPCX Enterprise R12.0 and above ¬ Communication Server redundancy ¬ Passive Communication Server local redundancy • Alcatel-Lucent OXO Connect 3.1 and above
  • Software upgrades
    • TFTP/HTTP/HTTPS
  • Power
    • IEEE 802.3af Power over Ethernet (POE) Class III • Power supply: 100-240 V AC/ 13.5 V DC
  • Environmental conditions
    • Operating temperature: +5° C (+41° F) / +40° C (+104° F) • Relative humidity: 20% to 80% condensation-free
  • Radio
    • EN 300 328 • FCC Part 15 subpart C • RSS-210
  • Human exposure
    • EN 62311 • FCC KDB447498 • RSS-102
  • Product ships with
    • 3MG08015AA: ¬ 8135s IP Conference Phone ¬ 6.5 m (21 ft.) network cable ¬ Safety sheet • 3MG07040AA ¬ 8135s IP Conference Phone ¬ 6.5 m (21 ft.) network cable ¬ Power supply ¬ Two expansion microphones ¬ Safety sheet
  • Accessories
    • Power supply: 3GV28133AA • Two expansion microphones: 3GV28134AA ¬ 1.5 m (5 ft.) cable and 2.5 m (8 ft.) cable included ¬ Increase the range from 30 m2 to 70 m2, that is more than double the range
